Portable big Solar Power Bank Panel Lamp emergency USB charging LED Lighting System Generator field Solar Battery Charger Indoor Home outdoor camping sites hotel emergency multi-purpose lighting
Instructions:
Please make the battery fully charged for first time
The light bulb cable is inserted into the jack marked
The charging system is a high-capacity battery, when it is fully charged
|
Number of bulbs (a) |
Lighting time when fully charged |
|
1bulb |
30 hours |
|
2bulbs |
15 hours |
High-brightness light bulb power supply system configured in 90 lumens brightness
Battery capacity indicator:
The first three indicators: electricity consumption is 50 to 100%
The first two indicators: electricity consumption is 20 to 50%
The first one indicator: capacity is less than 20%
Tips: If the lamp for high-brightness Led lamp is lit, do not stare.
Charging System
When using solar panels to charge, before normal operation in the following ways
1. When charging, the solar panels are placed in strong sunlight direction
2. wires connected solar panels sun logo jack, when the light flashes slowly, it shows its normal charge
In order to make the charging efficiency, proceed as follows:
1. solar panels placed on the sunny direction, and there are places to avoid shadows covered
2. Regularly use a damp cloth to clean the surface thereof, to avoid dust and dirt absorb sunlight during the
3. When charging the charging system in a cool place so that you can improve the charging efficiency
4. by smart chip to control the charging, when the solar panels should not have pulled out
Phone charging steps:
1. USB cable is inserted into the phone jack marked with the symbol
2. connector to connect the phone
Product Specifications
|
Solar panels |
3w 9v |
|
Cable length |
3 m |
|
Battery |
6v 4.5 AH |
|
Light bulb |
0.9W, 100LM |
|
Color |
6000 ~ 7000K |
|
Light line |
3m |
|
USB Output |
5V 500mah |
Battery maintenance and use of skills
In order to make the battery last longer, charging system using a 6v 4.5Ah lead acid batteries.
1. Do not expose the battery to place non-rechargeable
2. Even if not using, at least every three months on one charge
When replacing the battery, use only 6v lead acid battery, and under the guidance of professionals moreChange
